Convert Delphi to Java

Conversion Samples of Delphi to Java Swing

Ispirer Toolkit analyzes all object dependencies during the conversion process and provides not only line-by-line conversion, but resolves type conversions as well. The software understands and transforms the necessary inheritance dependencies. It parses the entire source code, builds an internal tree with all the information about the objects, and uses it in the migration process.

The code samples below provide you with more details.

• Variables declaration conversion:

  Delphi


  var 	CanClose: Boolean;
  		CustNo: Double;
  		DBPath: string;
  		Key: Char;
  		I: Integer;
  		RSCON: TIniFile;


  → Java Swing


  boolean CanClose;
  Double CustNo;
  String DBPath;
  char Key;
  Integer I;
  Wini RSCON;


• .pas file structure conversion:

  Delphi


  unit Splash;

  interface

  uses
    SysUtils, Windows, Messages, Classes, Graphics, Controls,
    Forms, Dialogs, StdCtrls, ExtCtrls;

  type
    TSplashForm = class(TForm)
      Panel1: TPanel;
      Label3: TLabel;
      Bevel1: TBevel;
      Label1: TLabel;
      Image1: TImage;
    end;

  var
    SplashForm: TSplashForm;

  implementation

  {$R *.dfm}

  end.


  → Java Swing


  package units;
  import handlers.TSplashFormHandler;
  import org.slf4j.Logger;
  import org.slf4j.LoggerFactory;

  public class Splash {
     private static Splash instance;
     private static final Logger LOGGER = LoggerFactory.getLogger(Splash.class);
     public TSplashFormHandler SplashForm;

     private Splash() {
     }

     public static synchronized Splash getInstance() {
        if(instance == null) {
           instance = new Splash();
        }
        return instance;
     }
  }



  package handlers;
  import forms.TSplashForm;
  import units.Splash;

  public class TSplashFormHandler {
     public TSplashForm form;

     public TSplashFormHandler(TSplashForm form) {
        this.form = form;
        form.setTSplashFormHandler(this);
     }
  }


• .dfm file structure conversion:

  Delphi


  object SplashForm: TSplashForm
    Left = 204
    Top = 123
    AutoScroll = False
    ActiveControl = Panel1
    BorderIcons = []
    BorderStyle = bsNone
    ClientHeight = 178
    ClientWidth = 168
    Font.Color = clBlack
    Font.Height = -11
    Font.Name = 'MS Sans Serif'
    Font.Style = []
    PixelsPerInch = 96
    Position = poScreenCenter
    TextHeight = 13
    object Panel1: TPanel
      Left = 0
      Top = 0
      Width = 168
      Height = 178
      Align = alClient
      BevelInner = bvLowered
      Color = clSilver
      TabOrder = 0
      object Label3: TLabel
        Left = 23
        Top = 125
        Width = 123
        Height = 19
        Caption = 'Marine Adventures'
        Font.Color = clBlack
        Font.Height = -16
        Font.Name = 'Times New Roman'
        Font.Style = [fsItalic, fsUnderline]
        ParentFont = False
      end
      object Bevel1: TBevel
        Left = 10
        Top = 150
        Width = 147
        Height = 2
        Style = bsRaised
      end
      object Label1: TLabel
        Left = 60
        Top = 158
        Width = 47
        Height = 13
        Caption = 'Loading...'
      end
      object Image1: TImage
        Left = 40
        Top = 11
        Width = 87
        Height = 113
        Picture.Data = {
          }
      end
    end
  end


  → Java Swing


  package forms;
  import javax.swing.*;
  import javax.swing.border.TitledBorder;
  import javax.swing.plaf.FontUIResource;
  import java.awt.*;
  import com.ispirer.sw.controls.TForm;
  import com.ispirer.sw.controls.TImage;
  import com.ispirer.sw.types.image.PictureUtils;
  import handlers.TSplashFormHandler;
  import org.apache.commons.lang3.StringUtils;

  public class TSplashForm extends TForm {
     private static final long serialVersionUID = 1L;
     private TSplashFormHandler tSplashFormHandler;

     private JPanel Panel1 = null;
     private JLabel Label3 = null;
     private JLabel Label1 = null;
     private TImage Image1 = null;
     public JPanel getPanel1() {
        return this.Panel1;
     }
     public JLabel getLabel3() {
        return this.Label3;
     }
     public JLabel getLabel1() {
        return this.Label1;
     }
     public TImage getImage1() {
        return this.Image1;
     }
     public TSplashForm() {
        setUIFont(new FontUIResource("MS Sans Serif", Font.PLAIN, 11));
        setDefaultCloseOperation(DISPOSE_ON_CLOSE);
        setName("SplashForm");
        setBorderStyle(BorderStyle.BS_NONE);
        setBounds(204, 123, 168, 178);
        setLocationRelativeTo(null);
        initTSplashForm();
        initLayouts();
     }
     private void initTSplashForm() {
        this.Panel1 = new JPanel() {
           @Override
           protected void paintComponent(Graphics g) {
              super.paintComponent(g);
              g.drawLine(10, 150, 157, 150);
              }
           };
        this.Label3 = new JLabel();
        this.Label1 = new JLabel();
        this.Image1 = new TImage();
        //
        // Panel1
        //
        this.Panel1.setName("Panel1");
        this.Panel1.setBounds(0, 0, 168, 178);
        this.Panel1.setLayout(null);
        this.Panel1.setBackground(Color.lightGray);
        getContentPane().add(this.Panel1, 0);
        //
        // Label3
        //
        this.Label3.setName("Label3");
        this.Label3.setForeground(Color.black);
        this.Label3.setBounds(23, 125, 123, 19);
        this.Label3.setText("<html><u>Marine Adventures</u></html>");
        this.Label3.setFont(new Font("Times New Roman", Font.ITALIC, 15));
        this.Label3.addPropertyChangeListener("text", labelChangeText);
        this.Panel1.add(this.Label3);
        //
        // Label1
        //
        this.Label1.setName("Label1");
        this.Label1.setBounds(60, 158, 47, 13);
        this.Label1.setText("Loading...");
        this.Label1.addPropertyChangeListener("text", labelChangeText);
        this.Panel1.add(this.Label1);
        //
        // Image1
        //
        this.Image1.setName("Image1");
        String Image1Data = StringUtils.join("");
        this.Image1.setImage(PictureUtils.getTImage(Image1Data));
        this.Image1.setBounds(40, 11, 87, 113);
        this.Panel1.add(this.Image1);
     }
     private void initLayouts() {
        GroupLayout contentPaneLayout = new GroupLayout(getContentPane());
        getContentPane().setLayout(contentPaneLayout);
        contentPaneLayout.setHorizontalGroup(contentPaneLayout.createParallelGroup(GroupLayout.Alignment.LEADING)
           .addComponent(Panel1, 0, 168, Short.MAX_VALUE));
        contentPaneLayout.setVerticalGroup(contentPaneLayout.createParallelGroup(GroupLayout.Alignment.LEADING)
           .addComponent(Panel1, 178, GroupLayout.DEFAULT_SIZE, Short.MAX_VALUE));
     }

     public void setTSplashFormHandler(TSplashFormHandler tSplashFormHandler) {
        this.tSplashFormHandler = tSplashFormHandler;
        setActiveControl(this.Panel1);
     }
  }


• If statement conversion:

  Delphi


    if FromEdit.Text = '' then Result := 0
    else Result := StrToDate(FromEdit.Text);


  → Java Swing


  if(form.getFromEdit().getText() == null && "".equals(form.getFromEdit().getText().trim())) {
           result = null;
        } else {
           result = LocalDateTime.from(LocalDate.parse(form.getFromEdit().getText(), DateTimeFormatter.ofPattern("M/d/yyyy")).atStartOfDay());
        }


• For statement conversion:

  Delphi


    for I := 0 to Application.ComponentCount - 1 do
    begin
      if Application.Components[I] is TForm then
      begin
        F := TForm(Application.Components[I]);
        if (F <> Self) and (F.Visible) then F.Close;
      end;
    end;


  → Java Swing


  for(I = 0; I <= Window.getWindows().length - 1; I ++) {
           if(Window.getWindows()[I] instanceof TForm) {
              F = (TForm) Window.getWindows()[I];
              if((F != this.form) && F.isVisible()) {
                 F.dispose();
              }
           }
        }


• While statement conversion:

  Delphi


  while not Items.EOF do
  Items.Delete;


  → Java Swing


  while(!form.getItems().isEOF()) {
              form.getItems().delete();
           }


• Try catch statement conversion:

  Delphi


    try
      Items.First;
    finally
      DeletingItems := False;
    end;


  → Java Swing


              try
              {
                  Items.MoveFirst();
              }
              finally
              {
                  DeletingItems = false;
              }
